Leak Detection in Glendale, CA — Find It Before You Open a Wall
The difference between a $300 pipe repair and a $3,000 drywall-and-remediation project is often just whether the leak was found before or after excessive wall opening. Our Leak Detection service in Glendale uses the same detection methods utilities and insurance adjusters rely on — to pinpoint the failure location before anything is cut.
No single detection method works for every leak scenario. Our technicians are trained on four distinct approaches and select the right tool — or combination of tools — based on the pipe type, building construction, and leak characteristics.
🎙️
Acoustic Ground Microphone
Acoustic detection is most effective on metal pipe (copper, cast iron) under slab or in concrete — materials that conduct sound efficiently. It works in quiet environments and requires shutting off the house briefly to establish a clean acoustic baseline.
🌡️
Infrared Thermal Camera
Active water leaks — hot or cold — create a temperature differential on the surfaces they contact. An infrared camera shows these differentials as color-coded heat maps, revealing the wet zone inside a wall or under a floor without any cutting. A cold water leak behind drywall appears as a spreading blue-gray cool zone; a hot water leak shows the inverse.
📉
Pressure Decay Testing
We isolate the supply system, pressurize it to operating pressure, and monitor pressure over a timed hold period. Any pressure drop confirms active water loss from the supply side. By isolating zones — hot side vs. cold side, section by section — we narrow down which branch of the supply system is leaking before the detection phase begins.
💨
Tracer Gas Detection
For leaks that don't produce sufficient acoustic signature — very slow leaks, polyethylene pipe, or leaks deep under concrete — we can introduce a nitrogen/hydrogen tracer gas mixture into the isolated pipe and use a calibrated gas detector at the surface to find where the gas escapes. The detection sensitivity can locate leaks that produce no discernible pressure drop during a standard timed test.
What We Locate
Every Leak Detection Scenario We Handle in Glendale, CA
Our detection service covers the full property, not just the obvious locations.
Under Slab
Slab Leak Detection
Confirmed slab leak location is documented with a marked point on the floor and provided to you in the written detection report, with coordinates relative to fixed reference points for the repair crew.
In-Wall
In-Wall & Ceiling Leak Detection
Wall and ceiling leaks are often traced by following a visible stain to its apparent high point — but the visible damage can be several feet from the actual pipe failure due to how water travels down framing members. Thermal imaging reveals the wet zone accurately, and acoustic equipment confirms the pipe location within the wall cavity.
Water Main
Underground Supply Line Detection
We mark the ground above the detected leak location so the repair crew opens only the section they need to.
Pool & Irrigation
Pool Line & Irrigation Leak Detection
Irrigation system leaks in main supply lines and lateral runs are found by isolating zones with the irrigation controller and pressure-testing each zone individually. Zone by zone testing narrows the failure to the smallest possible section.
Commercial
Commercial Property Leak Detection
Commercial water loss from undetected leaks often shows up as elevated utility bills for months before physical evidence appears. We can assess a commercial building's plumbing system for suspected leaks at the property owner's or property manager's request.
Documentation
Leak Detection Report for Insurance
We format detection reports specifically for insurance submission and can provide documentation on our detection equipment and methodology to claims adjusters on request.
Our Systematic Leak Detection Approach in Glendale
Here's exactly how a Masters Plumbing Service leak detection call plays out.
1
Initial Water Loss Confirmation
This step confirms we're looking for a real leak rather than meter error or a normal appliance cycling.
2
Zone Isolation & Pressure Decay
We isolate the supply system into zones — hot side, cold side, and if possible, individual branches — and pressure-test each zone to determine which branch is losing water. This narrows the area of active search significantly before detection equipment is deployed.
3
Detection Equipment Deployment
Within the isolated zone, we deploy thermal imaging first — scanning walls, floors, and ceilings for moisture anomalies. Then acoustic equipment confirms the specific pipe location and narrows it to the tightest possible point. Tracer gas is added if acoustic results aren't conclusive.
4
Written Report & Repair Options
Insurance claims: the report is formatted to support a claim for water damage from a concealed leak. We can provide supplemental documentation on request.
Customer Reviews
Real Leak Detection Reviews from Glendale
★★★★★
My water bill doubled over three months with no change in usage. Masters Plumbing Service came out, confirmed the meter was moving with everything off, isolated the cold supply to the kitchen as the failing branch, and used the acoustic device on the slab to pinpoint a location 4 feet from the outside wall under the kitchen floor. The repair crew opened a 10-inch circle in the tile, found a pinhole in a copper elbow exactly where detection said it would be. I was skeptical acoustic detection was that precise — it was.
— C. Thornton, Glendale
★★★★★
Our insurance company required professional leak detection documentation before approving the claim. Masters Plumbing Service's written report with pressure test data and thermal imagery was exactly what the adjuster needed. Claim approved. The detection cost was covered as part of the claim.
— B. Osei, Glendale, CA
★★★★★
Commercial building where water costs were running 40% above baseline for six months. Masters Plumbing Service ran a systematic zone-by-zone pressure isolation across four floors, narrowed the loss to the third-floor kitchen supply branch, and located the failure with thermal imaging at a concealed valve body in the ceiling. No damage to the finished ceiling.
— T. Anand, Glendale, CA
Common Questions
Leak Detection Questions from Glendale, CA Property Owners
Secondary indicators: water stains appearing or recurring in the same area without an obvious source; mold or mildew smell in rooms without a plumbing fixture; soft or discolored flooring; consistent sound of running water in walls when all fixtures are off.
In most cases, yes — the detection phase is entirely non-invasive. We locate the leak using acoustic, thermal, and pressure methods without any demolition. The detection tells us exactly where to open, which means the access opening is minimal rather than speculative.
For leaks in plastic pipe, low-pressure situations, or high-noise environments, accuracy may be lower and tracer gas becomes the preferred supplemental method.
We can provide supplemental information to claims adjusters on request, including equipment calibration records and a technical description of the detection methodology used.
A standard residential leak detection — confirming water loss, isolating the failing zone, and deploying detection equipment to locate the failure — typically takes 1.5–2.5 hours. More complex scenarios (multi-zone commercial, large properties, very slow leaks requiring tracer gas) can run 3–4 hours.
Yes — and for most residential leaks, we can repair the failure the same day detection confirms the location. Our service trucks carry the repair materials for the most common supply line failures. We quote the repair as a flat-rate job separate from the detection fee, and you decide whether to proceed with us or take the detection report to your own plumber.
Service Area
Leak Detection Available Across Glendale, CA
Masters Plumbing Service provides professional Leak Detection for residential and commercial properties throughout Glendale and the surrounding Glendale, CA service area. Detection appointments available most weekdays and Saturdays.
Non-Invasive Leak Detection in Glendale, CA — Book Your Appointment
Masters Plumbing Service's detection team finds hidden leaks in Glendale homes and commercial properties using equipment that eliminates guesswork. The detection appointment pays for itself the moment it prevents one unnecessary wall opening.
